1) Values and types

Every expression evaluates to one of these types:

• Number: a single numeric value at each time index (most common).

• Series: a time-aligned numeric series (what charts plot).

• Boolean (logical): internally represented as 1 or 0 (still numeric so it can be charted and composed).

• Null / NaN: invalid or unavailable value at a timestamp (propagates in a predictable way).

Core rule: everything becomes a number per bar. Even conditions like BTC.rsi > 70 produce a numeric output series of 1s and 0s.

2) Time alignment and indexing

All computations are evaluated per timestamp on the chart’s timeline.

• If you reference BTC.rsi and ETH.macd, the engine aligns them by timestamp.

• If one series has no value at a timestamp, that point becomes null (or is dropped if the consumer requires strict continuity).

• Rolling functions require enough history; early bars are null until n bars exist.

Rule: the engine will never “peek” forward. A value at time t can only depend on values at t and earlier.

3) Names and references

A variable reference has the semantic form:

• ASSET.operation Examples: BTC.close, ETH.volume, SOL.rsi

Semantics:

• ASSET resolves to an instrument in the view context (or global symbol list).

• operation resolves through the operation registry (built-in indicators + formula operations).

• The result is a series (or a scalar derived from a series if the operation is scalar-by-design).

4) Literals

Supported literal types:

• Numbers: 2, 2.5, 0.7233

• Function arguments can mix literals and references.

Semantics: literals are treated as a constant series over time when combined with series.

Example: BTC.close / 2 means “divide each bar of BTC.close by 2.”

5) Operators and precedence

Operators act pointwise over time.

Arithmetic:

• + - * /

Comparisons (return 1 or 0):

• > < >= <= == !=

Logical (return 1 or 0):

• AND OR

Precedence (highest → lowest):

1. Parentheses ( )

2. Unary -x (negation)

3. * /

4. + -

5. Comparisons > < >= <= == !=

6. AND

7. OR

Semantics:

• Arithmetic combines numbers/series pointwise.

• Comparisons produce a binary series (1/0).

• Logical operators treat non-zero as true.

6) Null / NaN propagation

Missing values propagate in a conservative way.

• Arithmetic: if either side is null → result null.

• Comparisons: if either side is null → result null (not false).

• Logical: if either side is null → result null, unless the logic can be determined without it (optional engine optimization, but default is conservative).

This prevents “fake certainty” near boundaries, early rolling windows, or missing markets.

7) Function calling semantics

Functions are pure and deterministic. They do not mutate state.

General form:

• functionName(arg1, arg2, ...)

Arguments can be:

• series references (BTC.rsi)

• nested expressions (normalize(BTC.volume / ETH.volume))

• literals (30)

Rules:

• Functions validate arity (number of args) and types.

• If the function is rolling and requires n, then first n-1 outputs are null.

8) Multi-input aggregation semantics

These functions combine multiple inputs and return a single output series.

composite(A, B, C, ...)

Meaning:

• Normalize each input to a comparable range (engine-defined, typically 0–100 or z-scored).

• Take the equal-weight average.

Use when you want “overall score” behavior.

weighted(w1:A, w2:B, w3:C, ...)

Meaning:

• Each wi is a literal weight.

• Engine normalizes weights so they sum to 1 (unless strict mode is enabled).

• Inputs are normalized before weighting (unless the function defines otherwise).

Use when BTC should dominate, but you still want diversification.

9) Statistical semantics

correlation(X, Y)

Meaning:

• Pearson correlation over the maximal overlapping history window (or default window).

• Returns a series (or scalar depending on implementation; in SEIOO you typically want a series).

rollingCorrelation(X, Y, n)

Meaning:

• For each time t, correlation is computed over [t-n+1 ... t].

• Early bars are null until n points exist.

10) Normalization semantics

normalize(X)

Meaning:

• Transform X into a comparable scale so it can be combined with unrelated units (price vs RSI vs volume).

• Typically outputs 0–100 or a standard score depending on the configured normalizer.

Rule: normalization is a semantic promise: “this number is now comparable to other normalized numbers.”

11) Signal semantics: turning values into interpretable scores

Many built-in indicators produce raw values (Layer 1) and can optionally produce signals (Layer 2) scaled into a fixed range (often 0–10).

Semantic idea:

• BTC.rsi is a value series.

• A signal form (if exposed) represents interpretive scoring using a normalizer (threshold/sigmoid/linear).

If your UI has a “signal mode,” the meaning is: “convert raw numeric indicator into an interpretable score on a common scale.”

12) Safety semantics (what is forbidden)

A formula is rejected if it attempts to do anything outside the grammar:

• No arbitrary identifiers beyond allowed tokens

• No property access except ASSET.operation

• No loops, assignments, imports, or JavaScript constructs

• No side effects

• No filesystem, network, or runtime access

Meaning: the DSL is not a programming language, it is a financial expression language.

How to script formulas

A practical guide to writing correct expressions.

A) Start with asset references

BTC.close
ETH.volume
SOL.rsi

B) Combine with math

BTC.close - BTC.open
(BTC.high + BTC.low) / 2
BTC.volume / ETH.volume

C) Add conditions (binary signals)

BTC.rsi > 70
BTC.rsi < 30 OR ETH.rsi < 30
BTC.rsi > 50 AND BTC.volume > normalize(ETH.volume)

These return a 1/0 series that you can chart or feed into other logic.

D) Use functions for higher-level meaning

normalize(BTC.volume)
rollingCorrelation(BTC.close, ETH.close, 30)
composite(BTC.rsi, ETH.macd, SOL.volume)
weighted(0.6:BTC.rsi, 0.3:ETH.rsi, 0.1:SOL.rsi)

E) Compose functions with expressions

composite(
  normalize(BTC.volume),
  normalize(ETH.volume),
  normalize(SOL.volume)
)

(BTC.rsi > 70) AND (rollingCorrelation(BTC.close, ETH.close, 30) > 0.8)

F) Common scripting patterns

Market breadth style composite

composite(BTC.rsi, ETH.rsi, SOL.rsi, XRP.rsi)

Risk-on / risk-off proxy

rollingCorrelation(BTC.close, NASDAQ.close, 60)

Condition gating

(BTC.rsi > 55) AND (BTC.volume > normalize(BTC.volume))

G) Determinism rule of thumb

If two users run the same formula on the same data and timeframe, they must get the same result. If an expression could introduce ambiguity, the engine rejects it rather than guessing.
